The oscillator pulse modulator
tubes with the output power from 12 to 3500 kW and thyratrons with
commutation current up to 5000 A are intended for operating in modulators
of radio transmitters, medical instrumentation and accelerators of
fundamental particles. They are also used as high frequency invertors in
industrial units.
|
Type |
Vf.
V |
If.
A |
Va. p.
kV |
F max.
MHz |
Poutput p.
kW |
Overall dimensions
(LxD) mm |
Mass
Kg |
|
Powerful pulse
triodes |
| ГИ-5Б |
6,6 |
465 |
27 |
200 |
1200 |
450 х 180 |
12 |
| ГИ-19Б-1 |
7,5 |
23 |
14 |
150 |
230 |
220 х 100 |
2,5 |
| ГИ-24Б |
6,6 |
465 |
27 |
200 |
800 |
441 х 180 |
12 |
| ГИ-35А |
7,8 |
200 |
14 |
200 |
225 |
253 х 181 |
7,5 |
| ГИ-35Б |
7,8 |
200 |
14 |
200 |
225 |
338 х
167 |
9 |
| ГИ-42Б |
14,2 |
585 |
35 |
150 |
3500 |
440 х 233 |
30 |
| ГИ-50А |
13,7 |
560 |
32 |
170 |
2000 |
420 х 210 |
18 |
|
Pulse
tetrodes |
| ГИ-58А |
4,2 |
125 |
11 |
175 |
12 |
215 х
85 |
3 |
|
Pulse modulator
tetrodes |
|
Type |
Vf.
V |
If.
A
|
Va.
kV |
Ia. p.
A |
Overall dimensions
(LxD) mm |
Mass
g |
| ГМИ-7-2 |
26 |
5,6 -
6,4 |
22 |
52 |
186 х
120 |
800 |
| ГМИ-26Б |
12,6 |
5,0 -
6,0 |
10 |
20 |
144 х
82 |
700 |
| ГМИ-27Б |
12,6 |
5,0 -
6,0 |
10 |
20 |
144 х
94 |
750 |
| ГМИ-38-1 |
26 |
3,0 -
3,4 |
20 |
24 |
145 х
86 |
520 |
|
